LA 988 | Automatic Button Feeder (Motor)

Loiva LA 988 Automatic Button Feeder with Motor – HCA Sewing Automation

Automatic Button Feeder (Motor)

Sale priceRs. 0.00
Sold out

Description

The Loiva LA 988 is a high-performance automatic button feeder equipped with a precise stepper motor system. Designed for efficiency and automation, it features a PLC-integrated control system with fast processing, ensuring accuracy and minimal downtime.

Key functionalities include a one-click width and thickness measurement system for adapting to various button sizes, and a dual-size mode that allows seamless switching between two button types in a single program—no manual reinsertions required.

The LA 988 is built for quiet operation and longevity with its motorized feeding system. An anti-collision mechanism ensures operator safety during continuous operation. It's compatible with two-hole buttons and supports a second thread trimming for a clean finish.

Ideal for high-volume garment production requiring precision and speed.


Specification

  • Model: LA 988
  • Button Diameter: 9–28 mm
  • Button Sewing Speed: 40–50 pcs/min
  • Feeding Speed: 60–65 pcs/min
  • Feeding Stability: 99.7%
  • Voltage: 220V
  • Power: 80W
  • Air Pressure: 0.3–0.35 Mpa
  • Package Size: 620 × 540 × 510 mm
  • Weight: 45 kg
