DY 6800D-4-24/AT | High-Speed, Direct-Drive Stepper Motor Controller Lock Machine With Automatic Trimmer

High-Speed, Direct-Drive Stepper Motor Controller Lock Machine With Automatic Trimmer

High-Speed, Direct-Drive Stepper Motor Controller Lock Machine With Automatic Trimmer

Rs. 0.00
Sold out

Description

The Duke DY 6800D-4-24/AT represents the next generation of industrial overlock technology. Engineered for high-volume garment manufacturing, it combines a powerful direct-drive system with advanced stepper motor controls to deliver unmatched precision, whisper-quiet operation, and significant labour savings.

Specification

  • Model: DY 6800D-4-24/AT
  • Max. Sewing Speed: 7,000 r.p.m
  • Needle Type / Size: DCx27#11
  • Number of Needles: 2
  • Number of Threads: 4
  • Max. Stitch Length: 3.8mm
  • Stitch Width: 4.0mm
  • Presser Foot Lift: 5.5mm
  • Differential Feed Ratio: 0.7–2.0
  • Automatic Thread Trimmer: Yes
  • Drive Type: Direct-Drive/Stepper Motor Control

Feature

Advanced Stepper Motor Control: Experience ultra-precise fabric feeding, reduced vibration, and highly accurate stitch consistency even at peak operational speeds.

Intelligent Automatic Trimmer (AT): Boosts productivity and minimizes material waste by automatically trimming threads cleanly at the end of each cycle.

Direct-Drive Efficiency: The integrated direct-drive motor ensures instant start/stop responsiveness, eliminates energy loss from traditional belts, and drastically cuts power consumption.

Ergonomic Smart Panel: Simple, intuitive interface allows operators to adjust speeds, toggle automatic trimming, and program stitch configurations on the fly.
