Description

Advanced Intelligent Duke Direct Drive Single Needle Lockstitch Machine

The DY-9503-D1 is a high-performance, intelligent sewing machine designed for precision stitching, energy efficiency, and smooth operation. Built with advanced direct-drive
technology, it ensures faster response, reduced noise, needle position and long-term durability-making it ideal for modern garment production units.

Specification

  • Model: DY 9503-D1
  • Machine Type: Single Needle Lockstich
  • Needle Range: #9 - #14
  • Number of Needles: 1
  • Stitch Length: 0-5 mm
  • Presser Foot Lift: By Hand: 6 mm | By Knee: 13 mm
  • Needle Bar Stroke: 32 mm
  • Motor Type: Inbuilt Servo Motor
  • Motor Power: 550W
  • Maximum Sewing Speed: 5000RPM

Feature

  • Single Needle Precision - Suitable for fine to medium
    fabrics.
  • Direct Drive Motor - Integrated 550W motor for rapid
    response.
  • Adjustable Light - Built-in, user-friendly illumination for
    better visibility.
  • Auto-Needle Positioning - Precision stopping reduces
    errors and fatigue /eliminate adjustment and keep your
    rhythm trough every seam.
  • Energy Efficient- Up to 70% power saving vs. clutch motors.
  • Low Noise & Vibration- Low noise and vibration due to
    direct drive technology.
  • High-Speed Output - Max speed of 5,000 SPM for mass
    production.
  • Auto Lubrication System - Keeps internal parts clean and
    reduces wear.
  • Reduced Thread Breakage - Optimized thread path and
    tension control minimize thread breakage for uninterrupted
    sewing.
